Trigger Setup
Trigger Type Trigger Condit
ions
Video
Trigger on spe
cified fields or lines of a composite video
signal. Only composite signal formats are supported.
Trigger on NTSC, PAL, or SECAM. Works with
Macrovision s
ignals.
With the D PO4VID module, trigger on a variety of HDTV
video standard signals, and custom (non-standard)
bilevel and t
rilevel video signals with 3 to 4,000 lines.
Bus Trigger on v
arious bus conditions.
I
2
C requires a DPO4EMBD module.
SPI requires a DPO4EMBD module.
CAN requir
es a DPO4AUTO or DP O4AUTOMAX
module.
RS-232, RS-422, RS-485, and UART require a
DPO4COMP m
odule.
LIN requires either a D PO4AUTO or a DPO4AUTOMAX
module.
FlexRay r
equires a DPO4AUTOMAX module.
Audio requires a DPO4AUDIO module.
USB requires a DPO4USB module.
Etherne
t requires a DPO4ENET module.
MIL-STD-1553 requires a DPO4AE RO module.
Parallel r equires an MSO 4000B S eries oscilloscope.
(See pa
ge 16, Application Module Free Trial.)
Triggering on Buses
You can use y our oscilloscope to trigger on multiple data buses, if you have the appropriate application module installed. The
MSO4000B Series can trigger on parallel buses without an application module. The oscilloscope can display both physical
layer (as analog waveforms) and protocol level information (as digital and symbolic waveforms).
To set u p the bus trigger:
1. If you have not already defined your bus
using the B1, B2, B3,orB4 buttons on
the front panel, do s o now. (See page 60,
Setting Up a Serial o r Parallel Bus.)
82 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
