Tektronix MSO4000B Series User Manual

Trigger Setup
Using Sequence Trigger (A (Main) and B (Delayed))
Combine an edge A Event (Main) trigger with the B Event (Delayed) trigger to capture m ore complex signals. After the A
Event occurs, the trigger system looks for the B Event before triggering and displaying the waveform.
A and B triggers can (and typically do) have separate sources.
Use the Edge trigger menu to set up the A trigger first. Then, to use the B trigger:
1. Push Trigger Menu.
2. Push Type.
3. Turn multipurpose knob a to select a trigger
type of Sequence (B Trigger).
This brings up the Sequence (B Trigger)
menu.
4. Push BTriggerAfterA.
Type
Sequence
(B Trigger)
Source
1
Coupling
DC
Slope
Level
0.00 V
B Trigger
After A
Time
Mode
Auto
& Holdoff
MSO4000B and DP O4000B Series Oscilloscopes User Manual 87

Tektronix MSO4000B Series Specifications

General

Analog Channels	2 or 4
Vertical Resolution	8 bits
Operating Temperature	0 °C to +50 °C
Digital Channels	16
Memory Depth/Record Length	20M standard on all channels
Display	10.4-inch (264 mm) LCD color display
Connectivity	Ethernet
Waveform Capture Rate	>50, 000 wfms/s
Trigger Types	Edge, Pulse Width, Logic, Setup/Hold, Rise/Fall Time, Video
Math Functions	FFT
Probe Interface	TekVPI
Power Requirements	100 to 240 V ±10%, 50/60 Hz
