Installation
13. S tart your browser on your remote computer.
In the browser address line, enter the host
name, a dot, an
d the domain name together.
Alternatively, just enter the IP address of
the instrument. Either way, you should then
see the LXI We
lcome page on your Web
browser on your computer screen.
14. Click “Netw
ork Configuration” to view and
edit the network configuration settings. If
you are using a password and changing
your settin
gs, y ou may need to know that
the default user name is “lxiuser”.
15. For e*Scop
e, click the Instrument Control
(e*Scope) link on the left side of the LXI
Welcome page. You should then see a new
tab (or wi
ndow) open in your browser with
e*Scope running.
Connecting a USB Keyboard to Your Oscilloscope
You can connect a USB keyboard to a USB Host port on the rear or front panel of the oscilloscope. The oscilloscope will
detect the keyboard, even if it is plugged in while the oscilloscope is powered on.
You can use the keyboard to quickly create names or labels. You can show the Label menu through the lower label button of
the Channel or Bus menus. Use the arrow keys on the keyboard to move the insertion point, and then type in a name or
label. Labeling channels and buses makes the information on the screen easier to identify.
To choose whether to use a keyboard with a United States (US) key layout or one with an alternative layout.
1. Push Utility.
2. Push Utility Page.
Utility
Page
Config
Language
Set Date &
Time
About Manage
Modules &
Options
3. Turn multipurpose knob a and select
Config.
4. Push Language on the lower menu.
5. Push USB Keyboard on the resulting side
menu.
6. Turn multipurpose knob a and select the
desired keyboard layout style from the
resulting menu.
30 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
