Acquire the Sign
al
FastACq
3. Toggle the Fas
tAcq side-menu button to
select On .
Fast Acq
On Off
4. Push Waveform Palette.
Waveform
Palette
a Temper-
ature
5. Turn the Mult
ipurpose a knob to select the
desired display palette.
The display palette lets you enhance the visibility
of events. T
his choice uses intensity grading to
indicate how often rare transients occur relative
to normal signals. The choices are Temperature,
Spectral,
Normal and Inverted.
Tem perature uses color-grading to indicate
frequency of occurrence with hot colors like
red/yello
w indicating frequently occurring events
and colder colors like blue/green indicating
rarely occurring events.
Spectral
uses color-grading to indicate
frequency of occurrence with colder colors like
blue indicating frequently occurring events and
hot colo
rs like red indicating rarely occurring
events.
Normal uses the default channel color (like
yellow f
or channel one) along with gray-scale
to indicate frequency of occurrence where
frequently occurring events are bright.
Invert
ed uses the default channel color
along with gray scale to indicate frequency of
occurrence where rarely occurring events are
bright
.
These color palettes help highlight the events
that over time occur more often or, in the case of
infre
quent anomalies, occur less often.
How t
he Analog Acquisition Modes Work
Sample mode retains the first sampled point
from each acquisition interval. Sample is the
def
ault mode.
54 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
