Analyze Wavefor
mData
3. Use the side me
nu and the multipurpose
knobs to adjust the vertical and horizontal
settings of the reference waveform.
R1
Vertical
0.00 div
100 mV/div
Horizontal
0.00 s
4.00 μs/div
Quick Tips
Selecting and Displaying Reference Waveforms. You can display all the reference waveforms at the s ame time.
Push the appropriate screen button to select a particular reference waveform.
Removing Reference Waveforms from the Display. To remove a reference waveform from the display, push R on the
front panel to access the lower menu. Then push the associated button from the lower m enu to turn it off.
Scaling and Positioning a Reference Waveform. You can position and scale a reference waveform independently
from all other displayed waveforms. Select the reference waveform and then adjust it with a multipurpose knob. You can
do this whether acquisition is running or not.
If a reference waveform is selected, scaling and repositioning of the reference w aveform operates the same way
whether zoom is turned on or off.
Saving 5M, 10 M and 20 M Reference Waveforms. 5M, 10 M and 20 M reference waveforms are volatile and not saved
when the oscilloscope power is turned off. To keep these waveforms, save them to external storage.
126 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
