Analyze Wavefor
mData
Search Description
Rise/Fall Tim
e
Search for ris
ing and/or falling edges that are >, <, =, or ≠ a user specified time.
Bus
Parallel: S e a
rch for a binary or hex value (MSO4000B Series only).
I
2
C: Search for Start, Repeated Start, Stop, Missing Ack, Address, Data, or Address and
Data.
SPI: Search f
or SS Active, MOSI, MISO, or MOSI & MISO
RS-232, RS-422, RS-485, UART: Search for Tx Start Bit, Rx Start Bit, Tx End of Packet, Rx
End of Packet, Tx Data, Rx D ata, Tx Parity Error, Rx Parity E rror
CAN: Search
for Start of Frame, Type of Frame (Data, Remote, Error, Overload), Identifier
(standard or extended), Data, Identifier and Data, End of Frame, or Missing Ack, Bit Stuffing
Error
LIN: Searc
h for Synch, Identifier, Data, ID & Data, Wakeup Frame, Sleep Frame, Error
FlexRay: Search for Start of Frame, Type of Frame, Identifier, C ycle C ount, Header Fields,
Data, ID & Data, End of Frame, Error
Audio: Sea
rch for Word Select or Data
USB: Search for Sync, Reset, Suspend, Resume, End of Packet, Token (Address) Packet,
Data Packet, Handshake Packet, Special Packet, or Error
Ethernet
: Search for Start of Frame, MAC Addresses, MAC Length/Type, MAC Client
Data, End of Packet, Idle, FCS (CRC) Error. If Q-(VLAN) Tagging is turned on, you c an
also search for Q-Tag Control Information.
MIL-STD
-1553: Search for Sync, Command, Status, Data, Time (RT/IMG), Error
132 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
