Tektronix MSO4000B Series User Manual

Appendix A: MSO/
DPO4000B Warranted Specifications
Table 2: Analog channel input and vertical specifications (cont.)
Characteristic Description
RMS noise (mV)
Instrument Bandwidth selection
1MΩ 50 Ω
Full Bandwidth
≤ (150 μV + 8.0% of
Volts/div setting)
≤ (75 μV + 6.0% of
Volts/div setting)
250 MHz bandwidth
limit
≤ (100 μV + 5.0% of
Volts/div setting)
≤ (50 μV + 4.0% of
Volts/div setting)
MSO4104B,
MSO4104B-L,
MSO4102B,
MSO4102B-L,
DPO4104B,
DPO4104B-L,
DPO4102B,
DPO4102B-L
20 MHz bandwidth
limit
≤ (100 μV + 5.0% of
Volts/div setting)
≤ (50 μV + 4.0% of
Volts/div setting)
Full Bandwidth
≤ (130 μV + 8.0% of
Volts/div setting)
≤ (130 μV + 8.0% of
Volts/div setting)
250 MHz bandwidth
limit
≤ (100 μV + 6.0% of
Volts/div setting)
≤ (100 μV + 6.0% of
Volts/div setting)
MSO4054B,
DPO4054B
20 MHz bandwidth
limit
≤ (100 μV + 4.0% of
Volts/div setting)
≤ (100 μV + 4.0% of
Volts/div setting)
Full Bandwidth
≤ (130 μV + 8.0% of
Volts/div setting)
≤ (130 μV + 8.0% of
Volts/div setting)
250 MHz bandwidth
limit
≤ (100 μV + 6.0% of
Volts/div setting)
≤ (100 μV + 6.0% of
Volts/div setting)
MSO4034B,
DPO4034B
20 MHz bandwidth
limit
≤ (100 μV + 4.0% of
Volts/div setting)
≤ (100 μV + 4.0% of
Volts/div setting)
Full Bandwidth
≤ (130 μV + 8.0% of
Volts/div setting)
≤ (130 μV + 8.0% of
Volts/div setting)
Random Noise,
Sample Acqui
sition
Mode
MSO4014B,
DPO4014B
20 MHz bandwidth
limit
≤ (100 μV + 4.0% of
Volts/div setting)
≤ (100 μV + 4.0% of
Volts/div setting)
MSO4000B and DP O4000B Series Oscilloscopes User Manual 189
