Operating basics
13. Unmount the USB
drive:
a. Press the up (▲)ordown(▼)arrowbuttontoselectTG8000 : UTILIT Y
: USB <status>
. The USB status should be Mounted
b. Press the ENTER button to unmount the USB drive. After the message
“You may now
safely remove the USB drive” is displayed, the menu
readout should change to TG8000 : UTILITY : USB (Not mounted).
c. Remove the U
SB drive from the instrument.
14. If your TG8000 includes an HDLG7 module, proceed with the following
steps to co
mplete the upgrade:
CAUTION. While upgrading, d o not press the front panel b uttons or cycle the
instrument power. Doing so can corrupt the module memory and FPGA image.
a. Power on the TG8000.
b. Press t
he MODULE button until the name of the HDLG7 module you are
upgrading a ppears.
c. Press
and hold the ENTER button until “Upgrade FPGA” appears.
d. Press the ENTER button to upgrade the module.
e. The upgrade will take approximately three minutes. After it is complete,
remove power from the TG8000 and then reapply power to reboot the
sys
tem.
NOTE. If you are upgrading the FPGA of multiple HDLG7 modules, you need
to upgrade them separately and reboot the instrument after each upgrade. For
example, if you have three HDLG7s, the FPGA upgrade process sequence will
be: s elect and upgrade a module, then reboot, then select and upgrade another
module, then reboot, select and upgrade the final m odule, then reboot. You do not
n
eed to upgrade the modules in any particular order.
2–64 TG8000 Multiformat Test Signal Generator User Manual
