AVG7 Analog Video Generator module
Table 3-8: AVG7 module signal sets assigned to the test signal buttons (cont.)
Button name Signal set Signals in the signal set
TIMING
—– —–
SDI
—– —–
OTHER Other FCC Composite, FCC Multiburst, Matrix 1, NTSC
Combination, NTC7 Composite, SNG Color Bars
PAL-1 format
COLOR BAR Color Bars 100% Color Bars, 75% Color Bars, 100% Color Bars
Over Red, 75% Color Bars Over Red
LINEARITY Linearity
5 Step, Modulated 5 Step, Modulated Ramp, Ramp
FLAT FIELD Flat Fields
Black Burst, 50% Flat Field, 100% Flat Field, Field
Square Wave
MULTI BURST
Multiburst
60% Multiburst, Multiplus
SWEEP Sweep 100% Sweep
MONITOR
Monitor
Convergence Pattern, Grey Window, White Window,
2 Level Pedestal & Pluge, 4 Level Pedestal & Pluge,
75% Red Field
PULSE BAR Pulse & Bar Window 2T Pulse & Bar, Sin X/X
TIMING
—– —–
SDI
—– —–
OTHER Other CCIR 17, CCIR 18, CCIR 330, CCIR 331, UK ITS
1, UK ITS 2
PAL-2 format
COLOR BAR Color Bars 100% Color Bars, 75% Color Bars
LINEARITY Linearity
10 Step, 5 Step, Modulated 10 Step, Modulated
5 Step, Modulated Ramp, Shallow Ramp, Ramp,
Modulated Pedestal
FLAT FIELD Flat Fields
Black Burst, 50% Flat Field, 100% Flat Field, Field
Square Wave
MULTI BURST
Multi Burst
100% Multiburst, 60% Multiburst
SWEEP Sweep 100% Sweep, 60% Sweep
MONITOR
Monitor
Convergence, Monitor Setup Matrix, 100% Red
Field, 75% Red Field, White Window, Safe Area
PULSE BAR Pulse & Bar 2T Pulse & Bar, Sin X/X
TIMING
—– —–
SDI
—– —–
OTHER Other ITS M atrix 1, UK 1 Line ITS
525 Beta format
COLOR BAR Color Bars 100% Color Bars, 75% Color Bars
LINEARITY Linearity
5 Step, Modulated Ramp, Ramp, Oversize Ramp,
Shallow Ramp Matrix, Valid Ramp, Valid 5 Step
TG8000 Multiformat Test Signal Generator User Manual 3–33
