Tektronix TG8000 User Manual

AVG7 Analog Video Generator module
Table 3-8: AVG7 module signal sets assigned to the test signal buttons (cont.)
Button name Signal set Signals in the signal set
FLAT FIELD Flat Fields
Black, 0% Flat Field, 100% Flat Field, 50% Flat
Field, Field Square Wave
MULTI BURST
Multi Burst
60% Multiburst
SWEEP Sweep 60% Sweep
MONITOR
Monitor
Convergence Pattern, Grey Window, White Window,
2 Level Ped. & Pluge, 4 Level Ped. & Pluge, 75%
Red Field, Chroma Noise
PULSE BAR Pulse & Bar 2T Pulse & Bar, TPulses
TIMING
Timing
50% Bowtie, 100% Bowtie
SDI
—– —–
OTHER Other
Test Matrix
525 GBR format
COLOR BAR Color Bars 100% Color Bars, 75% Color Bars
LINEARITY Linearity
5 Step, Shallow Ramp, Oversize Ramp, Shallow
Ramp Matrix, Luminance Ramp
FLAT FIELD Flat Fields
0% Flat Field, 100% Flat Field, 50% Flat Field, Field
Square Wave
MULTI BURST
Multi Burst
60% Multiburst
SWEEP Sweep 100% Line Sweep 5.5 MHz, 100% Line Sweep
8MHz
MONITOR
Monitor
Convergence Pattern, Grey Window, 2 Level Ped.
& Pluge, White Window, 4 Level Ped. & Pluge
PULSE BAR Pulse & Bar 2T Pulse & Bar
TIMING
Timing Bowtie
SDI
—– —–
OTHER
—– —–
525 YPbPr format
COLOR BAR Color Bars 100% Color Bars, 75% Color Bars
LINEARITY Linearity
5 Step, Ramp, Oversize Ramp, Shallow Ramp
Matrix, Valid Ramp, Valid 5 S tep, Modulated Ramp
FLAT FIELD Flat Fields
Black, 0% Flat Field, 100% Flat Field, 50% Flat
Field, Field Square Wave
MULTI BURST
Multi Burst
60% Multiburst
SWEEP Sweep 60% Sweep
MONITOR
Monitor
Convergence Pattern, Grey Window, White Window,
2 Level Ped. & Pluge, 4 Level Ped. & Pluge, 75%
Red Field, Chroma Noise
PULSE BAR Pulse & Bar 2T Pulse & Bar, T Pulses
TIMING
Timing
50% Bowtie, 100% Bowtie
3–34 TG8000 Multiformat Test Signal Generator User Manual
