Table 3-8: AVG7 module signal sets assigned to the test signal buttons (cont.)
Button name Signal set Signals in the signal set
SDI
—– —–
OTHER Other
Test Matrix
625 YPbPr form at
COLOR BAR Color Bars 100% Color Bars, 75% Color Bars, 100% Color Bars
Over Red, 75% Color Bars Over Red
LINEARITY Linearity
5 Step, Modulated Ramp, Ramp, Oversize Ramp,
Shallow Ramp Matrix, Valid 5 Step, Valid Ramp
FLAT FIELD Flat Fields
0% Flat Field, 100% Flat Field, 50% Flat Field, Field
Square Wave
MULTI BURST
Multi Burst
60% Multiburst
SWEEP Sweep 60% Sweep
MONITOR
Monitor
Convergence Pattern, Grey Window, White Window,
2 Level Ped. & Pluge, 4 Level Ped. & Pluge, 100%
Red, 75% Red
PULSE BAR Pulse & Bar 2T Pulse & Bar, T Pulses
TIMING
Timing
50% Bowtie, 100% Bowtie
SDI
—– —–
OTHER Other
Test Matrix
625 GBR format
COLOR BAR Color Bars 100% Color Bars, 75% Color Bars
LINEARITY Linearity
Oversize Ramp, Luminance Ramp, Shallow Ramp,
Shallow Ramp Matrix, 5 Step
FLAT FIELD Flat Fields
0% Flat Field, 50% Flat Field, 100% Flat Field, Field
Square Wave
MULTI BURST
Multi Burst
60% Multiburst
SWEEP Sweep 100% Sweep
MONITOR
Monitor
Convergence Pattern, Grey Window, 2 Level Ped.
& Pluge, White Window, 4 Level Ped. & Pluge
PULSE BAR Pulse & Bar Window 2T Pulse & Bar
TIMING
Timing Bowtie
SDI
—– —–
OTHER
—– —–
TG8000 Multiformat Test Signal Generator User Manual 3–35
