DVG7 Digital Video Generator module
EDIT. Edits the
text you want to display on the output test signal. Perform the
following steps to e dit the text:
NOTE. You can use up to 30 characters for the logo text. Use the blank character
to erase unneeded character(s).
1. Use the left (◄)orright(►)arrowbuttontoselectEDIT, and then press the
ENTER button to enable the text edit mode.
2. Use the left (◄)orright(►) arrow button to move the underscore character
(_) to the character you want to change.
3. Use the up (▲)ordown(▼) arrow button to select the desired chara cter.
4. After you
enter all of the desired characters, press the ENTER button to exit
the text editing mode.
5. Use the l
eft (◄)orright(►) arrow button to select SAVE, and then press the
ENTER button to save the text and its position to the signal file.
SAVE. Saves the text and its position to the signal file currently being output.
Press the ENTER button to save the text and its position to the signal file.
3–86 TG8000 Multiformat Test Signal Generator User Manual
