DVG7 Digital Video Generator module
DVG7 module
AUDIO GROUP submenu
Usethismenuto
perform the following tasks:
Enable or disable the embedded audio of the selected audio group.
Select which audio channel to enable.
Set the emphasis status bits, sampling alignment status bits, and sample bits
of the selected audio group.
Use the up (▲)ordown(▼) arrow button to scroll through the menu. The
following
figure shows the AUDIO GROUP submenu.
Figure 3-48: DVG7 module AUDIO GROUP submenu
Status. Enables or disables the generation of embedded audio for the selected
audio group. Use the left (◄)orright(►) arrow button to select between Enable
an
d Disable. Press the ENTER buttontoconfirm the selection.
Channel. Selects the audio channel for which you will change the parameters.
Use the left (◄)orright(►)arrowbuttontoselect1, 2, 3,or4 . Select any audio
channel, and then press the ENTER button to access the AUDIO CHANNEL
submenu. (See page 3-89.)
3–88 TG8000 Multiformat Test Signal Generator User Manual
