GPS7 GPS Synchronization and Timecode module
Table 3-22: Timing adjustment ranges for GPS7 output signals (cont.)
Format name Line settings Coarse settings (μs) Fine settings (ns)
1080 23.98sF ± 562 ± 37.0741 ± 7.00
1080 30p ± 562 ± 29.6296 ± 7.00
1080 29.97p ± 562 ± 29.6593 ± 7.00
1080 25p ± 562 ± 35.5556 ± 7.00
1080 24p ± 562 ± 37.0370 ± 7.00
1080 23.98p ± 562 ± 37.0741 ± 7.00
720 60p ± 375 ± 22.2222 ± 7.00
720 59.94p ± 375 ± 22.4444 ± 7.00
720 50p ± 375 ± 26.6667 ± 7.00
BLACK TIMECODE. Use this menu t o set timecode parameters for the selecte d
BLACK output. Press the ENTER button to acces s the TIMECODE submenu.
(See page 3-127.)
NOTE.
This submenu is available only when a non-HD format is set as the signal
format of the selected BLACK output.
BLAN
KONGPSUNLOCK. Use the left (◄)orright(►)arrowbuttontoturnON
or OFF the blanking function on the BLACK 2 output when a loss of lock to the
GPS/GLONASS signal is detected. When turned on, the BLACK 2 output will be
blanked as long as the loss of lock condition occurs. This purpose of this function
is to trigger a change-over. If configured to blank on loss of lock, this output
should not be used for normal reference applications.
N
OTE. This submenu is available only when BLACK 2 is the selected output.
TG8000 Multiformat Test Signal Generator User Manual 3–125
