GPS7 GPS Synchronization and Timecode module
If an SDI7 modul
e is installed, the SDI embedded timecode (when enabled) also
includes the SMPTE309 date, time-zone offset, and DST enabled/disabled fields.
The content of these fields depends on the current SMPTE309 mode setting on the
GPS7 module (Ignore, Use As Input, or Use As Input/Output).
The Status display for the module now includes the received ST309 time zone and
DST data (if present).
How to set the time-of-day in Internal mode. Perform the following steps to set the
Time of Day
in Internal mode.
1. Set the Time of Day source to Internal:
a. From the GPS7 module main menu, use the up (▲)ordown(▼) arrow
button to select TIME SETUP : SELECT MENU.
b. Use the left (◄)orright(►)arrowbuttontoselectTIME OF DAY
menu, and then press the ENTE R button.
c. In the TIME OF DAY submenu, use the left (◄)orright(►) arrow
button to select Source: Internal. Press the ENTER button to confirm
the se
lection.
2. Use the up (▲)ordown(▼)arrowbuttontoselectINTERNAL: <time>.
3. Press the ENTER button to enter the date and time edit mode.
4. Use the left (◄)orright(►) arrow button to select a digit in the time offset to
change. An underline character appears under the selected time digit. The
date and time digits take the following form: YYYY-MM-DD HH:MM:SS.
5. After you select an offset digit, use the up (▲)ordown(▼) arrow button to
change the value of the digit. Repeat for each digit as required for your date
an
d time.
CAUTION. When you press the ENTER button, this applies the start time and
date offset. Typically, this causes a disruption to the syncs, s o care should be
taken to verify the date and time are correct before activating Internal mode
time-of-day setting.
6. Press the ENTER to confirm the change and set the time.
NOTE. The manual time of day setting is not automatically reapplied when the
instrument power is cycled. If the instrument powers on in Internal mode, the time
of day w ill be acquire d from the real time clock in the instrument.
The time zone offset must be set to maintain the correct relationship between
UTC and local time.
TG8000 Multiformat Test Signal Generator User Manual 3–137
