HDLG7 HD Dual Link Video Generator module
The following t
able lists the signal set assigned to each test signal button and the
signals that can be selected in the signal set when the module is configured to
output projector test patterns. The table also lists the native XYZ projector test
patterns that correspond to digital cinema.
Table 3-42: HDLG7 module projector test pattern set assigned to the test signal
buttons
Button name Signal set Signals in the signal set
COLOR BAR Color Bars Color Bar Patch-1, Color Bar Patch-2
LINEARITY Linearity
Step Black-White, Step Black-Dark Gray,
Horizontal Gradient, Vertical Gradient
FLAT FIELD Flat Fields Black Flat Field, White Flat Field,
Black to White Step-1, Black to White Step-2,
Black to White Step-3, Black to White Step-4,
Black to White Step-5, Black to White Step-6,
Black to White Step-7, Black to White Step-8,
Black to White Step-9, Black to White Step-10,
Black to Gray Step-1, Black to Gray S tep-2,
Black to Gray Step-3, Black to Gray S tep-4,
Black to Gray Step-5, Black to Gray S tep-6,
Black to Gray Step-7, Black to Gray S tep-8,
Black to Gray Step-9, Black to Gray Step-10
MULTI BURST
—— ——
SWEEP
—— ——
MONITOR
Monitor
Red-1 Field, Red-2 Field, Green-1 Field, Green-2 Field,
Blue-1 Field, Blue-2 Field, Cyan-1 Field, Cyan-2 Field,
Magenta-1 Field, Magenta-2 F ield, Yellow-1 Field,
Yellow-2 Field, Grid, Checkerboard, Aspect Ratio
PULSE BAR P ulse & Bar
Window
TIMING
—— ——
SDI SDI Equalizer Test, PLL Test, SDI Matrix
OTHER
——
Use this button to select the converter mode of operation
and Embedded audio selection menu. (See page 3-221,
To select the Converter mode on the HDLG7 module.)
To set the gradient starting point.
When you select Horizontal Gradient or Vertical Gradient in the Linearity
projector test pattern set, use the up (▲)ordown(▼) arrow button to set the
starting point of the gradient. The available values are as follows:
Horizontal Gradient: 16 to 1913 in 1 level steps.
Vertical Gradient: 16 to 2880 in 1 level steps (2048 × 1080 format);
16 to 2404 in 1 level steps (2048 × 1556 format).
3–220 TG8000 Multiformat Test Signal Generator User Manual
