SDI7 Dual Channel SD/HD/3G SDI Video Generator module
Status. Displa
ys the status o f the logo overlay display. Use the left (◄)or
right (►) arrow button to select Disable or Enable. Press the ENTER button
confirm the selection.
Source. Displays the selected logo file. Use the left (◄)orright(►) arrow
button to select a logo file stored in the SDI7/LOGO directory. Press the ENTER
button confi
rm the selection.
The default logo is the "first" fi le in the SDI7/LOGO directory, as sorted by the
date of the
logo file (oldest first). If the factory-provided logo files are installed,
the default logo is “Tektronix_logo_500x125.bmp.”
However,
if the user has removed the factory-provided logo files and added their
own custom files, then the default logo will be the oldest file installed in the
SDI7/LOGO directory.
NOTE. The position of the logo overlay is referenced from the lower right of
the active raster area.
XPosi
tion. Sets the horizontal position of the logo. The position is set as a
percentage of active picture width. Use the left (◄)orright(►) arrow button to
change the position. You can set the value from -100.0% to -1.0% in 0.1% steps.
Press the ENTER button confirm the selection.
Y Position. Sets the vertical position of the logo. The position is set as a
per
centage of active picture height. Use the left (◄)orright(►) arrow button to
change the position. You can set the value from -100.0% to -1.0% in 0.1% steps.
Press the ENTER button confirm the selection.
3–296 TG8000 Multiformat Test Signal Generator User Manual
