7. Set the digital
audio monitor to display the status for the audio data.
8. Check that any CRC error does not appear on the monitor.
9. Change the BNC cable from the 1+2 connector to the 3+4 connector, and
check that no CRC errors appear on the monitor.
10. Change the BNC cable from the 3+4 connector to the 5+6 connector, and
check that no CRC errors appear on the monitor.
11. Change the BNC cable from the 5+6 connector to the 7+8 connector, and
check that no CRC errors appear on the monitor.
12. Change the BNC cable from the 7+8 connector to the SILENCE connector,
and check that no CRC errors appear on the monitor.
13. Connect the 48 kHz CLOCK connector to the oscilloscope CH1 input using
the 75 Ω BNC cable and 75 Ω termination.
14. Check that the appropriate clock signal is displayed on the screen.
AGL7 module functional
check
Use the following procedure to check that the AGL7 Analog Genlock module
is functional:
Required equipment.
TV signal generator
NTSC/PAL waveform monitor
HDTV waveform monitor
75 Ω BNC cable
75
Ω termination
Procedure.
1
.
I
nstall the module into the TG8000 mainframe. (See page 1-11.)
2. Power on the TG8000 mainframe by connecting it to the power source. The
initialization process for all installed modules is executed.
3. Check that no error messages appear on the LCD display.
4. Warm up the instrument for 20 minutes.
TG8000 Multiformat Test Signal Generator User Manual 1–17
