2. System Installation 11
2.2 Control Panel Installation
2.2.1 Selecting the Installation Location
The installation location of the control panel and the various devices shall
strongly inuence the efciency of the wireless alarm system.
In order to achieve best performance for the radio signal and respectively
for the good serviceability of your wireless alarm system, please follow the
recommendations given below.
Figure 8. A model situation of locating the AVA Control Panel and the wireless devices
enrolled in it.
Figure 9. Location of the AVA Control Panel and the wireless devices enrolled in it
within the premises. The Control Panel is located approximately within the centre of the
alarm system.
PIR detector
A V A P-Rex
PIR detector
A V A P-Rex
Outdoor siren
SR200R
Magnet
Contact
МС 100 ТЕ
Control
Panel
A V A
Remote
Control
RC 102 TE
LEGEND:
Fire Detector
Magnet Contact
PIR Detector
Control Panel
