22 Addressable Fire Panel IRIS - Installation and Programming Manual
3.2 Programming Menu
The programming of the panel is done only from the access level 3 - Fig. Screens 2. Choose the System
Button. From the next screen the Installer/User can choose the type of the operation, which he want to do:
1. To program system parameters - Programming Menu.
2. To study the panel operation, as to enter different parameters for the maintenance of the system -
Maintenance Menu.
Fig. Screens 2.
To enter in the Programming Menu the Installer should choose Programming Button. The main screen of
the Programming Menu is displayed on Fig. Screen 3.
Fig. Screen 3.
On the left side of the screen are located buttons for entering submenus for parameter programming of De-
vices, Zones, Inputs, Outputs and Access Codes. To enter a desired submenu just choose its button.
Choosing the button “Restore Defaults” on the right side of the screen can restore all the factory settings.
Button “Save” is for quick saving of the entered information.
With the button “Exit” in the bottom left corner the user/installer can easy move one
step back on the previous screen.
Devices
Zones
Inputs
Outputs
Panel
Restoring of the
factory settings
Buttons for quick saving of
the whole panel conguration
To Next Page
