36 Addressable Fire Panel IRIS - Installation and Programming Manual
3.7 Panel
Choose in sequence from the Main menu screen System - Programming - Panel.
From the Panel Menu you can switch over seven additional submenus and to change the access codes and
level, and to set parameters of the available network, sounders and call points modes.
Fig. Screen 19 - The Panel Menu.
The system supports 4 separate access codes, as to which of them can be given different access level. See
item 3.1 where are described the default setting of the codes and access levels. Every code has 4 digits.
Fig. Screen 20 - Codes and Access Level Introducing.
The new code introducing is done in a separate screen (see also Fig. Screens 1). After the code is initially en-
tered, the system shall request the code to be entered again for verication. If the codes differ the system will
ignore whatever was entered and the old code will remain active. If both codes are identical, the new code will
be displayed in the “ACCESS CODES” output eld and an “Apply” button will appear. Select “Apply” to save
the entered code. If a code has already been entered the system will ignore it and will retain the old one.
Changing the level of access is done by choosing the “Access Code Level” button next to the eld for calling
out the access level. When activated a menu appears in which the user selects a new level of access (1-3)
by pressing the respective button or “EXIT” to leave. If the newly assigned access level is different from the
current one, the “Apply” button will be activated. Pressing that will save the new access level.
There must be at least one code in the system with an access code 3! The pro-
gram disallows editing a level of access (3) if it is the only one!
