Addressable Fire Panel IRIS - Installation and Programming Manual 51

Icon Description
LOADING Mode - loads conguration data from permanent memory
SAVING Mode - saves conguration data in permanent memory
DAY Time Mode - processes signals from detectors with enhanced sensitivity (set for every
detector)
NIGHT Time Mode - processes signals from detectors with enhanced sensitivity (set for every
detector)
Evacuation when a common delay (Т1) for all outputs is set - blinks together with the output(s)
status icons, for which a time delay is set. In the respective output status icon is running countdown
presenting the time left to output activation. A continuos sound signal is heard till the countdown
is over.
Evacuation when output delay (Т2 - sirens, re, extinguishing) - blinks together with the
output(s) status icons, for which a time delay is set. In the respective output status icon is running
countdown presenting the time left to output activation. A continuos sound signal is heard till the
countdown is over.

Icon Colour Description
Red Sirens activated - activated output.
Black Sirens not activated - dormant output.
Grey The sirens are disabled - disabled output.
Red
(Blinks)
The sirens are delayed - delay is running prior to activation (programmable for every
zone). The icon blinks and the countdown time until activation is displayed.

Icon Colour Description
Red Fire output activated - activated output.
Black Fire output is not activated - dormant output.
Grey The re output is disabled - disabled output.
Red
(Blinks)
The re output is delayed - delay is running prior to activation (programmable for
every zone). The icon blinks and the countdown time until activation is displayed.

Icon Colour Description
Red Fire extinguishing output activated - activated output.
Black Fire extinguishing output is not activated - dormant output.
Grey The re extinguishing is disabled - disabled output.
Red
(Blinks)
The re extinguishing output is delayed - delay is running prior to activation
(programmable for every zone). The icon blinks and the countdown time until
activation is displayed.
