Teletek electronics IRIS - General Technical Specifications; Possible Hardware Configurations; Working Environment; Electrical Specification

6 Addressable Fire Panel IRIS - Installation and Programming Manual

• Loops - from 1 to 4 loops (Loop SS and/ or Loop TTE in a random combination)
• Up to 99 detectors and 99 modules per Loop SS
• Up to 250 devices (detectors and modules, regardless of the type) per Loop TTE
• Zones - 96 displayed zones
• Inputs - 4 programmable for volt-free Normal Open contact
• Monitored relay outputs - 4 (Sounder, Fire, Fault and Fire Protection)
• Non monitored relay outputs - 4 programmable, 230V/ 10A
• Display - 320x240 CSTN color graphic display (118.8 x 89.38 mm) with a touch panel
• Real time clock
• Up to 128 programmable Inputs/Outputs per panel
• Comprehensive day/night mode facility
• 2 Steps of alarm levels (T1 and T2)
• Based on Windows graphical conguration utility via Ethernet or USB
• Simple Http monitoring utility
• Loop less panel option (repeater)
• Thermal printer (optional)
• Flush mounting enclosure
• Multilanguage support
• Easy software update
• Compatible with the requirements of EN54-2/4

Maximum conguration:
- Main Board
- Power Supply Source
- LED-indication
- Input/Output Module
- 4 Relay Module
- 4 Loop Controllers (Loop SS and/ or Loop TTE)
- Modem
- Heat Printer (optional)

- Working Temperature: -10˚C up to +50˚C
- Relative Humidity: up to 95% (without condense)
- Storage Temperature: -10˚C up to +60˚C
- Weight (without the battery): 6kg.

Earth connection
The earth connection has to be realized in accordance with the rules for the electrical safety with the total
resistance in the circuit lower than 10Ω. It is mandatory to connect the main power supply cable to the middle
input of the re panel terminal - see .
Main power supply
In normal operating conditions the re panel is powered from the mains voltage line. In case of mains volt-
age line loss the re panel is equipped with one rechargeable battery. The characteristics of the main power
supply are as follows:
- Main Power Supply: ~230V ±10%
- Frequency: 50/ 60Hz
- Electrical output: 1A
ATTENTION: Do not instal the re panel near power electromagnetic elds (radio equip-
ment, electric motors, etc.)!
Minimum conguration:
- Main Board
- Power Supply
!
