TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
1.4.5 DVB-ASI/SMPTE-310M Input BNC Connectors
There are five input BNCs used to input DVB-ASI or SMPTE-310M format transport stream. The
format is detected automatically.
BNC-IN(DVB-ASI/SMPTE-
310M-1~5)
BNC type connector enables serial SMPTE-310M and/or DVB-
ASI transport stream input with automatic detection
The TLV-300E/TAV-900A accepts SMPTE-310M and DVB-ASI signal. These transport stream
formats can be transformed to another format (SMPTE-310M output is only available for
19,392,658 Hz bit rate signal source as SMPTE-310M is not compliant with other bit rate stream).
1.4.6 RF Input Connectors
RF Input 1 F type connector allows a radio frequency input.
(8VSB/64QAM/256QAM default, DVB-S2/S or DVB-T option)
RF Input 2 (option) Optional second F type connector allows a radio frequency
input. (8VSB/64QAM/256QAM or DVB-S2/S or DVB-T option)
1.4.7 Communication Port
There are two communication ports, these are:
ETHERNET 10/100M Ethernet port
USB Universal Serial Bus Connector (version 1.1)
An ETHERNET connector is used to monitor and control the receiver.
An USB 1.1 port is used to upgrade a firmware. FAT16 or FAT32 format USB memory is supported.
1.4.8 FAULT Output Port
Relay contact for fault condition indication. The fault condition can be configured from
CONFIG/FAULT OUT menu. FAULT is indicated by Open circuit and No Fault condition is indicated
by closed circuit into Ground.
1.4.9 Power Switch & Inlet
Power on/off switch and power inlet:
Version 2.0 16
