TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
SUB /AUDIO LANGUAGE, ENCODING, SAMPLING FREQ and CODING
MODE
SUB /PSIP PAT, PMT, MGT, VCT, EIT, and STT display
SUB /CAPTION EIA-708B Service Language display
3.3.3 STATUS/RF-IN1 and STATUS/RF-IN2 sub-menu
There are SNR, BER, and CONSTELLATION sub-menus in the RF-NI1 and RF-IN2 menus. The RF-IN1
and RF-IN2 sub-menus allow you to monitor the SNR/BER and CONSTELLATION of tuned RF.
Table 28 STATUS menu architecture
STATUS menu structure
RF-IN1 View RF status on RF input-1.
RF-IN1/SNR View current SNR of RF input-1.
RF-IN1/BER View current BER of RF input-1.
RF-
IN1/CONSTELLATION
View constellation of RF input-1.
RF-IN2 View RF status on RF input-2.
RF-IN2/SNR View current SNR of RF input-2.
RF-IN2/BER View current BER of RF input-2.
RF-
IN2/CONSTELLATION
View constellation of RF input-2.
3.3.4 STATUS/INPUT sub-menu
The INPUT sub-menu allows you to see information about input condition. You could see LOCK/UNLOCK
of RF-IN1, RF-IN2 and BNC-1 through 5 Input.
Version 2.0 47
