TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
RF-IN2/FREQUENCY
PLAN
Select channel plan. Mode can be TERRESTRIAL, STANDARD
CABLE, HRC CABLE, or IRC CABLE.
RF-IN2/MODULATION Select Modulation type: 8VSB, 64QAM, 256QAM.
RF-IN2/BER INTERVAL Select BER calculation interval
RF-IN2/EQUALIZER ON / OFF the channel equalizer of the demodulator. ON is
strongly recommended.
3.2.6 CONFIG/BNC OUT(AES/ASI/SMPTE310M) sub-menu
The BNC OUT(AES/ASI/SMPTE310M) sub-menu allows user to configure Output BNC connectors.
Choose BNC OUT(AES/ASI/SMPTE310M)-1~4 connector to deliver MAIN-ASI, MAIN-310M,
MAIN-AES3 or SUB-AES3. SMPTE-310M is not valid when QAM or DVB-ASI type source is
selected for MAIN input. MAIN-ASI means MAIN channel transport stream in DVB-ASI format.
MAIN-310M means MAIN channel transport stream in SMPTE-310M format. MAIN-AES3 means
MAIN channel audio in AES-3id format. SUB-AES3 means SUB channel audio in AES-3id format.
Table 19 CONFIG/BNC OUT submenu architecture
CONFIG
BNC
OUT(AES/ASI/SMPTE310M)
Configure BNC output mode.
BNC
OUT(AES/ASI/SMPTE310M)
/BNC-1
Choose BNC OUT(AES/ASI/SMPTE310M)-1 connector to
deliver MAIN-ASI, MAIN-310M, MAIN-AES3 or SUB-AES3.
SMPTE-310M is not valid when QAM or DVB-ASI type source is
selected for MAIN input. MAIN-ASI means MAIN channel
transport stream in DVB-ASI format. MAIN-310M means MAIN
channel transport stream in SMPTE-310M format. MAIN-AES3
means MAIN channel audio in AES-3id format. SUB-AES3
means SUB channel audio in AES-3id format.
BNC
OUT(AES/ASI/SMPTE310M)
/BNC-2
Choose BNC OUT(AES/ASI/SMPTE310M)-2 connector to
deliver MAIN-ASI, MAIN-310M, MAIN-AES3 or SUB-AES3.
Version 2.0 37
