TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
CVBS video.
Use CONFIG/MAIN/AUDIO/DIGITAL AUDIO COMPRESSED or PCM depending on the type of digital
audio receiver.
Use CONFIG/SUB/AUDIO/DIGITAL AUDIO COMPRESSED or PCM depending on the type of digital
audio receiver.
Other connector BNC OUT(AES3/ASI/SMPTE310M) - 3 and 4 connectors can be used as well.
2.11 USING FAULT OUTPUT
When fault condition happen, the FAULT OUT BNC will have open circuit and No fault condition will have
closed contact with ground.
Use CONFIG/FAULT OUT menu to define fault condition.
2.12 SNMP NETWORK MANAGEMENT
User can control the receiver by entering URL of the receiver from internet web browser. The
SNMP based controller is loaded from the receiver to the web browser and user can configure the
receiver just like configuring in front panel and can watch status of the receiver.
User need to install SUN Micro System Java VM on his PC by downloading JAVA SE or JAVA SDK
from
http://java.sun.com
.
Enter the IP address of the PC at CONFIG->NETWORK->NMS IP ADDR.
Activate CONFIG->NETWORK->SNMP AGENT.
Type the address of CONFIG->NETWORK-> IP ADDR from the web-browser like
http://192.168.0.240/
(if 192.168.0.240 is the IP address of the receiver).
The web NMS page has MIB file download link.
2.13 SAVING CONFIGURATION
User can save current configuration into non-volatile memory using SAVE-PROFILE menu and
recall it later. The RECALL-PROFILE menu allows you to recall the saved configuration profile. To
recall the profile, point the cursor to the desired position using Left/Right buttons and input the
desired index number using up/down buttons or numeric buttons. Select EXEC to recall.
2.14 MENU USING OSD
CONFIG/FAULT/MAIN/OSD, CONFIG/FAULT/SUB/OSD, STATUS/MAIN/PSIP and
Version 2.0 26
