TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
Max. input voltage (p-p) 880 mV
S11 (range: 0,1 to 1,0 x bit rate) -8dB
8.10 DVB-ASI OUTPUT
Output voltage (p-p) 800 mV± 10%
Deterministic jitter (DJ) (p-p) 10%
S11 (range: 0,1 to 1,0 x bit rate) -8dB
Random jitter (RJ) (p-p) 8%
Return loss –8dB
Maximum rise/fall time (20-80%) 1,2 ns
8.11 RF INPUT
Connector type F connector
Modulation type 8VSB/64QAM/256QAM
Bandwidth 6 MHz
Impedance 75 ohm
8.12 FAULT OUTPUT
Connector type BNC, female
Operation No fault: Closed Contact with Ground
Fault: Open Circuit
Relay rating Resistive load 0.5A 110VAC, 1A 24VDC
Inductive load 0.2A 110VAC, 0.5A 24VDC
Version 2.0 64
