TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
7. SPECIFICATIONS
1
Section Detailed section Explanation
Terrestrial Input
Signal
Input frequency 54 MHz ~ 820 MHz
Input impedance 75 ohm F-connector
Band width 6 MHz
Modulation type 8VSB, 64QAM/256QAM(ITU-T J.83 Annex
B)
TS Input Interface protocol SMPTE-310M at 19,392,58 bps rate.
DVB© ASI up to 80Mbps
TS output Interface protocol DVB© ASI / SMPTE-310M
Video Algorithm MPEG-2 compatible Main Profile@High
Level
Video bit rate 1.5 ~ 60 Mbit/sec
Display video type 1080i / 720p / 480p(576p) / 480i(576i)
selectable
Display frame rate 25Hz/29.97Hz/30Hz (Other frame rate
supported on request)
Video output 1 Component and SDI – HD and SD
Video output 2 Composite signal 480i/576i
Audio Algorithm Dolby AC-3, MPEG-1/2 layers 1 and 2
Frequency response 20Hz~ 20 kHz, < ± 2dB
Sampling frequency 48 kHz
Analog audio output XLR 2ch (L1,R1) and D-sub 9p (L2,R2)
Digital audio output AES3-id 75 ohm BNC connector
Version 2.0 58
