Teleview TAV900A - BNC Configuration

TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
Power Switch Turn on/off main power
Power Inlet Universal AC-INLET accepts 100–240 VAC and a line frequency
50/60 Hz. IEC C14 type chassis plug
RF IN-1 TLV300E MAIN:PbPr/RGB Out
MAIN: Sync Out
SUB:CVBS Out
MAIN:L1/R1(CH1/2)
AES3/TS OUT, BNC1
AES3/TS OUT, BNC2
AES3/TS OUT, BNC3
AES3/TS OUT, BNC4
MAIN:SDI OUT 1
MAIN:SDI OUT 2
FAULT OUT
USBETHERNET
SUB:L2/R2(CH1/2)
RF IN-2 (option)
TS IN, BNC1
TS IN, BNC2
TS IN, BNC3
TS IN, BNC4
TS IN, BNC5
Figure 8 Conceptual Drawing for Input/Output Connections
1.5 BNC CONFIGURATION
Four set of BNC connector is used for digital audio, SMPTE-310M and DVB-ASI output. Each
connector can be configured to MAIN / SUB digital audio output, SMPTE-310M, or DVB-ASI
output. Digital audio can be compressed audio or decoded PCM signal.
