TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
8.2 MAIN VIDEO OUTPUT – COMPONENT
Name Type Connector Description
Y/G OUT Luminance BNC, female 0.7Vpp at 75 ohm
Pb/B OUT Chrominance-blue BNC, female 0.7Vpp at 75 ohm
Pr/R OUT Chrominance-red BNC, female 0.7Vpp at 75 ohm
HD OUT Horizontal sync BNC, female 4 Vpp at 75 ohm
VD OUT Vertical sync BNC, female 4 Vpp at 75 ohm
Embedded sync signal on Y at YPbPr mode
8.3 MAIN VIDEO OUTPUT – SDI
Name Type Connector Description
SDI 1,2 SD - SDI BNC, female ITU-BR.601/SMPTE-259M
Embedded Audio SMPTE272M, 48kHz
IEC61937(Uncompressed),
IEC60958(Compressed – TBD)
SDI 1,2 HD-SDI BNC, female SMPTE292M, 1.485Gbps,
SMPTE274M(1080i),
SMPTE296M(720P)
Embedded Audio SMPTE299M, 48kHz
IEC61937(Uncompressed),
IEC60958(Compressed – TBD)
Embedded sync signal on Y at YPbPr mode
NOTE) If digital audio is set to COMPRESSED mode, Embedded Audio is disabled. Please set the digital
audio to PCM mode in order to enable the embedded audio.
Version 2.0 61
