TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
3 RXP
4 Not used
5 Not used
6 RXN
7 Not used
8 Not used
8.7 SMPTE-310M INPUT
Connector type BNC connector
Impedance 75 ohm
Bit rate 19,392,658 bps
Minimum signal level 200 mVpp
Maximum signal level 880 mVpp
Frequency tolerance Max 2.5 ppm
8.8 SMPTE-310M OUTPUT
Connector type BNC connector
Impedance 75 ohm
Bit rate 19,392,658 bps
Signal level 800 mVpp AC signal
Frequency tolerance Max 2.5 ppm
8.9 DVB-ASI INPUT
Min. sensitivity (D21.5 idle pattern) 200 mV
Version 2.0 63
