TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
3.2.9 CONFIG/FAULT OUT sub-menu
You could see error status using FAULT OUT menu. There are MAIN, SUB, INPUT PORT, and
THRESHOLD INTERVAL sub-menus.
Table 22 CONFIG/FAULT OUT sub-menu architecture
CONFIG
FAULT OUT Program fault condition of the receiver.
FAULT OUT/MAIN Program fault condition with MAIN channel audio/video
decoder.
FAULT OUT/MAIN/FAULT
OUT
Enable/disable error condition check. Error condition includes
TS UNLOCK, TS SYNC ERROR, TS CC ERROR, TS EACH
PID ERROR, TS PAT ERROR, DMX PAT ERROR, DMX PMT
ERROR, DECODER NO VIDEO, DECODER NO AUDIO, and
DECODER LIPSYNC ERROR.
FAULT OUT
/MAIN/THRESHOLD
Set threshold for each error condition, TS SYNC ERROR, TS
CC ERROR, TS EACH PID ERROR, TS PAT ERROR.
FAULT OUT/MAIN/OSD Enable fault status on screen display on MAIN display.
FAULT OUT/SUB Program fault condition with SUB channel audio/video decoder.
FAULT OUT/SUB/FAULT
OUT
Enable/disable error condition check. Error condition includes
TS UNLOCK, TS SYNC ERROR, TS CC ERROR, TS EACH
PID ERROR, TS PAT ERROR, DMX PAT ERROR, DMX PMT
ERROR, DECODER NO VIDEO, DECODER NO AUDIO, and
DECODER LIPSYNC ERROR.
FAULT
OUT/SUB/THRESHOLD
Set threshold for each error condition, TS SYNC ERROR, TS
CC ERROR, TS EACH PID ERROR, TS PAT ERROR.
FAULT OUT/SUB/OSD Enable fault status on screen display on SUB display.
FAULT OUT/INPUT PORT Program fault tolerance with each INPUT ports. RF-IN1, RF-
IN2, BNC-1, BNC-2, BNC-3, BNC-4 and BNC-5.
FAULT OUT/THRESHOLD
INTERVAL
Duration used to calculate error rates.(3sec, 5sec, 10sec)
FAULT OUT/MAIN: Fault output monitoring conditions for MAIN audio/video decoder path.
Version 2.0 40
