TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
8. INPUT AND OUTPUT SIGNAL SPECIFICATIONS
2
8.1 AUDIO OUTPUT
Name Type Connector Description
L1, R1 Analog audio output XLR Balanced 600 ohm, Audio L1
and R1
L2, R2 Analog audio output D-sub 9p Balanced 600 ohm, Audio L2
and R2
ASI/310/AES3
OUT
Digital audio output BNC, female Compressed / PCM
AES3id, Compressed
(AC3,MPEG, IEC60958) and
Uncompressed (IEC 61937)
D-sub 9p pin numbering
Pin number Name Description
1 L+ Analog 2
nd
audio LEFT+
2 L- Analog 2
nd
audio LEFT-
3 NC No Connection
4 R+ Analog 2
nd
audio RIGHT+
5 R- Analog 2
nd
audio RIGHT+
6 GND GND
7 NC No Connection
8 NC No Connection
9 GND GND
Version 2.0 60
