TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
Table 7 Available modes for SDI output
Video
Mode
Frame Rate Embedded Audio
29.97Hz(59.94) 30Hz(60) 25Hz(50) PCM Compressed
1080i O O O O O
720p O O O O O
480p/576p Not defined
(480p)
Not defined
(480p)
Not defined
(576p)
X X
480i/576i O (480i) Not supported
(480i)
O
(576i)
O O
Table 8 SDI Video Specification(FW v2.2.0, FPGA v3.1)
Display mode
1080i 720p 480i 1080i 720p 1080i 720p 576i
Frame rate
30/1.001
Hz
60/1.001
Hz
30/1.001
Hz
30Hz 60Hz 25Hz 50Hz 25Hz
Reference HD/SD-
SDI standard
SMPTE
292M
SMPTE
292M
SMPTE
259M
SMPTE
292M
SMPTE
292M
SMPTE
292M
SMPTE
292M
SMPTE
259M
HD/SD-SDI
parameter
1,2)
Format E Format M Level C Format D Format L Format F - Level C
Video Reference
SMPTE
standard
SMPTE
274M-
system 5
SMPTE
296M-
system 2
SMPTE 125M
or ITU-R
BT.601-5 part
A 525 line
system
SMPTE
274M-
system 4
SMPTE
296M-
system 1
SMPTE
274M-
system 6
SMPTE
296M-
system 3
3)
ITU-R
BT.601-5
part A 625
line system
Note 1) format D,E,F,L,M is supported from SMPTE 292M-1998 Table 1.
Note 2) Level-C, 270 Mb/s , 525/625 component mode is supported from SMPTE-259M-1997.
Note 3) Following SMPTE-296M-system 3.2, 720p/50Hz format is not specified by SMPTE-292M-
1998.
Version 2.0 20
