TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
Example) Table display:
MGT INFORMATION 2004-11-09
Version Proto.
Ver
Table Num. Table Type Table PID Table Ver.
8 0 16 0x0000 (T-VCT)
0x0201 (ETT)
0x0202 (ETT)
0x0004 (ETT)
0x1Hb
0x1e00
0x1e01
0x1e80
15
25
24
15
UP/DN: display another info, SLCT: toggle Hex÷Dec.
Figure 11 MGT information display
VCT: For displaying information about the VCTs (Virtual Channel Table) in the stream. There are as many
VCTs per stream as channels in an ATSC compliant Transport Stream. If there are two or more available
VCT, press ENTER/SLCT to select next available VCT [Program No.].
Example) Table display:
VCT INFO / REPLACEMENT 2004-11-09
Prog. No. Name SRC Id. Mod. Mode Major No. Minor No.
1 TLV →→→ 1 4 9 1
Freq. TS Id. ETM Loc. CAS Hidden SRV type
477250000 1041 1 0 0 2
AVAILABLE VCT [Program No.] TOTAL
1 1
#: Enter new Major no., ,< / > choose VCT, SLCT: VCT replacement.
Figure 12 VCT information display
EIT: For displaying information about the EITs (Event Information Table) in the stream. An event is a
collection of elementary streams with a common time base, an associated start time and an associated
end time. There are many EITs in an ATSC compliant transport stream. Each EIT lists TV programs
(Events) for the virtual channels described in the VCT. If there are two or more available EIT, press
ENTER/SLCT to select next available EIT [Event Id.].
Version 2.0 45
