TLV-300E/TAV-900A Professional Digital TV Receiver User’s Manual
SUB/VIDEO/FRAME RATE 29.97Hz
SUB/VIDEO/ASPECT RATIO 16:9
SUB/VIDEO/SCREEN MODE LETTER BOX
SUB/AUDIO/DIGITAL AUDIO PCM only. No Compressed Audio
(Remaining SUB settings are as same as MAIN
settings.)
RF-IN1/TUNE CENTER FREQ 473000KHz
RF-IN1/TUNE CH 002
RF-IN1/FREQENCY PLAN TERRESTRIAL
RF-IN1/MODULATION 8VSB
RF-IN1/BER INTERVAL 1 SEC
RF-IN1/EQUALIZER ON
(RF-IN2 settings are as same as RF-IN1 menus.)
BNC OUT(AES/ASI/SMPTE310M)/BNC-1 MAIN-ASI
BNC OUT(AES/ASI/SMPTE310M)//BNC-2 MAIN-310M
BNC OUT(AES/ASI/SMPTE310M)//BNC-3 MAIN-AES3
BNC OUT(AES/ASI/SMPTE310M)//BNC-4 SUB-AES3
SYSTEM/LOCAL TIME OFFSET 0.0
NETWORK/DHCP ON
NETWORK/NMS IP ADDRESS 192.168.000.001
NETWORK/SNMP AGENT ACTIVE
FAULT OUT/MAIN/FAULT OUT USE (FOR ALL SETTINGS)
