Tenda O6 User Manual

Web UI login
- 11 -
3 Web UI login
3.1 Login
When using the device for the first time, you can log in to its web UI via a browser with default login information.
The default login information includes:
Item
Default Setting
IP Address
192.168.2.1
Username and Password
admin
To log in to this device:
(Assume that the AP is in factory default state and ensure that your PC is connected to the device.)
1. Set your PC’s IP address to 192.168.2.X (2~254).
>> Method 1: Set your PC to Obtain an IP address automatically.
>> Method 2: Manually set your PC to 192.168.2.X (2~254), with a subnet mask of 255.255.255.0. (If the
switch and AP are in the same IP segment, make sure that the switch, AP and PC have different IP addresses).
For detailed steps, see Appendix Configure your computer.
Tip
The AP’s DHCP server is enabled by default. Once you finished settings on Quick Setup page, the DHCP server
will be disabled automatically.
Or

Tenda O6 Specifications

General

Internal	No
Placement	Wall
Reset button	Yes
Certification	FCC/CE/RoHS
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Channel bandwidth	35 MHz
Transmitting power	1 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	433 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Input current	0.5 A
AC input voltage	24 V
Power consumption (max)	9 W
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	16 dBi
USB 2.0 ports quantity	0
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.5 mm
Width	94.9 mm
Height	270 mm
