Tenda O6 User Manual

Web UI Functions
-14-
4 Web UI functions
4.1 Status
This page displays system info, wireless info, and related statistics information of the device. Click Status to enter
the setup page, and pull the scroll bar to view more information.
Parameter Description (part of): (You can also click on the upper right page to get help.)
Parameter
Description
System Info
Running time: The duration of time that the device has been running from last reboot. It will be
reset when the device reboots.
System Time: The device’s current system time. To ensure that time-related functions work
properly, go to Tools > Date & Time to set up an appropriate system time.
LAN/WAN MAC: MAC address of PoE LAN/WAN port. In router mode, it is WAN MAC address
and in other modes, it is LAN MAC address. If you set up MAC Clone function in router mode,
you can check on this page whether it is successful.

Tenda O6 Specifications

General

Internal	No
Placement	Wall
Reset button	Yes
Certification	FCC/CE/RoHS
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Channel bandwidth	35 MHz
Transmitting power	1 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	433 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Input current	0.5 A
AC input voltage	24 V
Power consumption (max)	9 W
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	16 dBi
USB 2.0 ports quantity	0
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.5 mm
Width	94.9 mm
Height	270 mm
