Tenda O6 User Manual

Web UI Functions
-15-
WLAN MAC: MAC address of the wireless interface of the device.
LAN/WAN: Indicates the connection status of PoE LAN/WAN port.This can indicate that a cable
is not plugged into a device, there is no active Ethernet connection, or the current rate of PoE
LAN/WAN port. (In router mode, PoE LAN/WAN port works as a WAN port. In other modes, it
works as LAN port.)
Wireless Info
Working mode: Current operation mode of the device. For the working modes supported by the
device, please see Operation mode description.
SSID: Current wireless network name of the device.
Security Mode: Current wireless encryption mode of the device. For detailed encryption
information, please see Encryption method description.
Channel/Bandwidth: Current working channel and bandwidth of the device.
Wireless Clients: Number of wireless clients currently connected to SSID of the device.
AP MAC: Wireless MAC address of this device or a remote AP.
 In AP mode and router mode, it is the wireless MAC address of this device.
 In other modes, if this device is connected to another AP wirelessly, AP MAC address is the
wireless MAC address of that remote AP.
Signal strength: Wireless signal strength of the connected device.
 If this device is connected to another AP wirelessly, it is the wireless signal strength of that
remote AP.
 In AP mode and router mode, it is the wireless signal strength of the wireless client that is
first connected to this device.
Noise Floor: Background noise of the current environment. The greater the absolute value, the
less the interference.
TX/RX link: The number of independent spatial data streams that the device is transmitting (TX)
and receiving (RX). This device is Single-Input Single-Output.
TX/RX rate: (Available in Station/Universal Repeater/WISP mode.) Displays the current 802.11
data transmission (TX) and data reception (RX) rates.
Statistics
Throughput: The current data traffic on wireless interface and LAN port in both graphical and
numerical form.The chart scale and throughput dimension (Bps, Kbps, Mbps) change
dynamically depending on the mean throughput value.The statistics are updated automatically.

Tenda O6 Specifications

General

Internal	No
Placement	Wall
Reset button	Yes
Certification	FCC/CE/RoHS
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Channel bandwidth	35 MHz
Transmitting power	1 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	433 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Input current	0.5 A
AC input voltage	24 V
Power consumption (max)	9 W
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	16 dBi
USB 2.0 ports quantity	0
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.5 mm
Width	94.9 mm
Height	270 mm
