Tenda O6 User Manual

Web UI Functions
-32-
Parameter
Description
MAC Address
This device’s MAC address of LAN port.
Address Type
Select a method to set up the LAN IP address.The default method is Static IP.
 Static IP: In this method, you need to manually set up LAN IP address. If you modified
LAN IP address, when you log in to the device’s web UI, please use the new IP address. If
you change LAN IP segment, please change your computer’s IP segment to the new one
as well.
 DHCP: In this method, the device can obtain LAN IP address from another DHCP server. In
this way, it reduces IP conflict and the cost of configuring IP address manually. If your
device obtains LAN IP address from a DHCP server of an uplink router and you don’t know
the IP address, you can log in to the uplink router’s web UI to check the obtained IP
address.
IP Address
It is used to log in to the device’s web UI and communicate with the local network. The
default one is 192.168.2.1.
Subnet Mask
It is used to determine IP segment of the IP address. The default one is 255.255.255.0
Default gateway
It helps the device find a network route to connect to the internet or other networks.
Preferred DNS
server
Domain names, such as www.google.com, are easier to remember than IP addresses, such
as 93.46.8.89. A correct DNS server allows you to access websites using their domain names
instead of IP addresses.
Alternate DNS
server
It is a backup DNS server address.
Device Name
Enter a distinct name for your device so that the administrator can manage the device from
a remote spot if necessary.
Static IP: Set up LAN IP address manually
In this method, you need to manually set up LAN IP address. If you modified LAN IP address, when you log in to
the device’s web UI, please use the new IP address. If you change LAN IP segment, please change your computer’s
IP segment to the new one as well.

Tenda O6 Specifications

General

Internal	No
Placement	Wall
Reset button	Yes
Certification	FCC/CE/RoHS
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Channel bandwidth	35 MHz
Transmitting power	1 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	433 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Input current	0.5 A
AC input voltage	24 V
Power consumption (max)	9 W
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	16 dBi
USB 2.0 ports quantity	0
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.5 mm
Width	94.9 mm
Height	270 mm
