Tenda O6 User Manual

Web UI Functions
-35-
Parameter description
Parameter
Description
DHCP Server
Enable/disable the device’s DHCP server. By default, it is enabled.
Start IP
The first IP address that can be assigned to a DHCP client. By default, it is 192.168.2.100.
End IP
The last IP address that can be assigned to a DHCP client. By default, it is 192.168.2.200.
Subnet Mask
It is used to determine the IP segment of the DHCP server. By default, it is 255.255.255.0.
Default gateway
It is assigned to DHCP clients so that they can find a network path to access the internet or
other networks. By default, it is 192.168.2.254.
Preferred DNS
Server
Domain names, such as www.google.com, are easier to remember than IP addresses, such
as 93.46.8.89. A correct DNS server allows you to access websites using their domain names
instead of IP addresses.
Alternate DNS
Server
It is a backup DNS server address.
Lease Time
When a DHCP client obtains IP address, the DHCP server will assign a certain lease time to
the client's IP address. If a DHCP client wants to use the IP address continuously, when the
lease time goes to 50%, the DHCP client will transmit a unicast DHCP request to the DHCP
server. If the DHCP client gets no response from the DHCP server, it will continue to transmit
a unicast DHCP request to the DHCP server when the lease time goes to 7/8. If it fails again,
when the lease time goes to 100%, the IP address will be released and might be used by
other DHCP clients.
Configure DHCP server
Note
If more than one DHCP server exists in the same network, to avoid IP conflict, make sure the IP pool of each DHCP
server doesn’t overlap.
To configure DHCP server:
1. Log in to the device’s web UI.
2. Go to Network > DHCP Server.
3. Set up DHCP server parameters.
1) DHCP Server: Check the box of Enable.

Tenda O6 Specifications

General

Internal	No
Placement	Wall
Reset button	Yes
Certification	FCC/CE/RoHS
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Channel bandwidth	35 MHz
Transmitting power	1 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	433 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Input current	0.5 A
AC input voltage	24 V
Power consumption (max)	9 W
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	16 dBi
USB 2.0 ports quantity	0
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.5 mm
Width	94.9 mm
Height	270 mm
