Tenda O6 User Manual

Web UI Functions
-75-
Configure MAC filter
Assume that you want to forbid a client with MAC address C8:3A:35:03:11:79 from accessing the Internet at 18:00
to 20:00 on Monday to Friday. The Setup steps are as follows:
To configure MAC filter function:
1. Log in to the device’s web UI.
2. Go to Advanced > MAC Filter.
3. Click Add.
4. In the pop-up window, set up the parameters.
1) Filtering Rule: Click the dropdown list and select Forbid only.
2) Remarks: Description of setting a rule, for example, forbid accessing the Internet.
3) MAC Address: Enter a MAC address of a client that is forbidden from being connecting to the AP (in this
example, C8:3A:35:03:11:79).
4) Time: Click the dropdown list and select a point in time when the rule is effective (in this example,
18:00~20:00).
5) Day: Click the dropdown list and select a date when the rule is effective (in this example, Monday to
Friday).
5. Click Save to finish settings.

Tenda O6 Specifications

General

Internal	No
Placement	Wall
Reset button	Yes
Certification	FCC/CE/RoHS
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Channel bandwidth	35 MHz
Transmitting power	1 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	433 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Input current	0.5 A
AC input voltage	24 V
Power consumption (max)	9 W
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	16 dBi
USB 2.0 ports quantity	0
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.5 mm
Width	94.9 mm
Height	270 mm
