Service and Repair Manual August 2021
Scissor Components
94 GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
27 Attach a lifting strap from an overhead
supporting device to the number 4 outer arm
(index #13).
28 Remove the external snap rings and retaining
fasteners from the number 4 center pivot pins
(index #2).
29 Use a soft metal drift to remove the number
4 center pivot pins (index #2).
30 Remove the retaining fasteners from the
number 4 pivot pin (index #14) at the non-
steer end of the machine.
31 Use a soft metal drift to remove the number
4 pivot pin (index #14) from the non-steer end
of the machine. Remove the number 4 outer
arm (index #13) from the machine.
Crushing hazard. The number
4
outer arm may become
unbalanced and fall if not
properly supported when
removed from the machine.
32 Remove the number 4 cable bridge mounting
fasteners and remove the cable bridge from
the machine.
33 Attach a lifting strap from an overhead
supporting device to the number 4 inner arm
(index #12).
34 Remove the retaining fasteners from the
number 4 pivot pin (index #3).
35 Use a soft metal drift to remove the number
4 pivot pin (index #3) at the steer end.
Remove the number 4 inner arm (index #12)
from the machine.
Crushing hazard. The number
4
inner arm may become
unbalanced and fall if not
properly supported when
removed from the machine.
36 Remove the cables from the number 3 cable
bridge and lay them off to the side.
Component damage hazard.
Cables can be damaged if they
are kinked or pinched.
37 Remove the number 3 cable bridge mounting
fasteners and remove the cable bridge from
the machine.
38 Attach a lifting strap from an overhead
supporting device to the number 3 outer arm
(index #4) at the ground controls side.
39 Remove the external snap rings and retaining
fasteners from the number 3 center pivot pins
(index #4).
40 Use a soft metal drift to remove the number
3 center pivot pin (index #4) at the ground
control side.
41 Remove the retaining fasteners from the
number 3 pivot pin (index #17) at the non-
steer end of the machine.
42 Use a soft metal drift to tap the number
3 pivot pin (index #17) halfway out at the non-
steer end of the machine. Remove the
number 3 outer arm (index #16) at the ground
controls side from the machine.
Bodily injury hazard. The
number
3 outer arm at the
ground controls side may
become unbalanced a
nd fall if
not properly supported when
removed from the machine.
43 Attach a lifting strap from an overhead
supporting device to the number 3 outer arm
(index #16) at the battery pack side.
44 Use a soft metal drift to remove the number
3 center pivot pin (index #4) at the battery
pack side of the machine.
