Service and Repair Manual August 2021
Type "FXXX" Faults
196 GS
™
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
Type "FXXX" Faults
DTC
Number
Message on
GCON LCD
Description Possible Causes Failure Mode
F001:
F001:SWITCHFAULT
UP LIMIT1:BAT+
Short circuit of the up limit #1 switch
at system startup.
• Short circuit of the up limit switch circuit.
• Up limit #1 switch short circuit.
• GCON ECM.
Platform up function inhibited.
F003:
F003:SWITCHFAULT
DOWN LIMIT1:BAT+
Short circuit of the down limit
#1 switch at system startup.
• Short circuit of the down limit switch circuit.
• Down limit #1 switch short circuit.
• GCON ECM.
All functions inhibited except
platform down.
F005:
F005:SWITCHFAULT
POTHOLE:BAT+
Short circuit of the pothole limit
#1 switch at system startup.
• Short circuit of the pothole switch circuit.
• Pothole limit #1 switch short circuit.
• GCON ECM.
All functions inhibited except
platform down as long as
machine is in the elevated
position. If machine is in
stowed position, all
functionality is resumed.
F007:
F007:SWITCHFAULT
CHASSISTILT:BAT+
Short circuit of the chassis digital tilt
switch at system startup.
• Short circuit of the chassis digital tilt switch circuit.
• Chassis digital tilt switch short circuit.
• GCON ECM.
All functions inhibited except
platform down as long as
machine is in the elevated
position. If machine is in
stowed position, all
functionality is resumed.
F008:
F008:SENSORFAULT
OVLD XDUCER:BAT+
Short circuit of the Platform Overload
Transducer circuit to battery positive.
• Short circuit in the transducer circuit.
• Faulty pressure transducer.
• GCON ECM.
All functions inhibited.
F009:
F009:SENSORFAULT
OVLD XDUCER:BAT-
Short circuit of the Platform Overload
Transducer circuit to battery negative.
• Short circuit in the transducer circuit.
• Faulty pressure transducer.
• GCON ECM.
All functions inhibited.
F010:
F010:SENSORFAULT
PLAT HEIGHT:BAT+
Short circuit of the Platform Height
Sensor circuit to battery positive.
• Short circuit in the platform height circuit.
• Faulty platform height sensor.
• GCON ECM.
All functions inhibited except
platform down as long as
machine is in the elevated
position. If machine is in
stowed position, all
functionality is resumed.
F011:
F011:SENSORFAULT
PLAT HEIGHT:BAT-
Short circuit of the Platform Height
Sensor circuit to battery negative.
• Short circuit in the platform height circuit.
• Faulty platform height sensor.
• GCON ECM.
All functions inhibited except
platform down as long as
machine is in the elevated
position. If machine is in
stowed position, all
functionality is resumed.
