Terex Genie GS-1330m User Manual

August 2021 Service and Repair Manual
Specifications
Part No. 1309020GT GS
™
-30m • 32m • 30 • 32 • 46 • 55 9
Hydraulic Component
Specifications
GS-1330m
Function Pump
Type
gear pump
Displacement per revolution
0.094 c
u in
1,54 c
c
Flow rate @ 1500 psi / 103 bar
1.3 g
pm
4,9 L/min
Hydraulic tank return filter
10 m
icron
25 psi / 1,7 b
ar bypass
Function manifold
System relief valve pressure, maximum
2250 p
si
155 b
ar
Steer relief valve pressure
1600 p
si
110 bar
GS-1432m, GS-1932m, GS-1932m Lite, GS-1932 XH
Function Pump
Type
gear pump
Displacement per revolution
0.165 c
u in
2,7 c
c
Flow rate @ 240
0 psi / 165 bar
1.7 g
pm
6,5 L/min
Hydraulic tank return filter
10 m
icron
23 psi / 1,6 b
ar bypass
Function manifold
System relief valve
pressure, maximum
GS
-1432m
1800 p
si
124 b
ar
GS
-1932m, GS-1932m Lite,
GS-1932m XH
2400 p
si
165 bar
GS-1530, GS-1532, GS-1930, GS-1932, GS-1932 XH
Function Pump
Models with hydraulic drive
Type
gear pump
Displacement per revolution
0.244 cu in
4 c
c
Flow rate @ 250
0 psi / 172 bar
3 g
pm
11,3 L/min
Hydraulic tank return filter
10 m
icron
25 psi / 1,7 b
ar bypass
Models with electric drive
Type
gear pump
Displacement per revolution
0.092 c
u in
1,5 c
c
Flow rate @ 250
0 psi / 172 bar 1.2 g
pm
4,5 L/min
Hydraulic tank return filter
10 m
icron
18 psi / 1,2 b
ar bypass
Function manifold
Models with hydraulic drive
System relief valve pressure, maximum
3700 p
si
255 b
ar
Models with electric drive
System relief valve pressure, maximum
GS
-1530, GS-1532
2700 p
si
186 b
ar
GS-1930, GS-1932, GS-1932 XH
3500 psi
241 b
ar
