August 2021 Service and Repair Manual

Manifolds

Part No. 1309020GT GS

™

-30m • 32m • 30 • 32 • 46 • 55 55

5-8

Function Manifold Components – Models with hydraulic drive,

GS-2032, GS-2632

The function manifold is mounted behind an inspection door, at the ground control side of the machine.

Note: 'alpha-numeric' callouts refer to corresponding notes on the electrical schematic.

Index No. Description

Schematic

Item

Function Torque

—

Coil nut

AC —

4-5 ft-lbs / 5-

7 Nm

—

Coil nut

AE, AG, AI —

5-7 ft-lbs / 7-

9 Nm

Diagnostic port

Test port

—

Relief valve, 3700 psi / 255 bar

System relief

20 ft-

lbs / 27 Nm

Solenoid valve,

3 position 4 way AC Steer left/right

25 ft-

lbs / 34 Nm

Check valve

AK Lift circuit

23 ft-

lbs / 31 Nm

Check disc

AD Steer circuit

18 ft-

lbs / 24 Nm

Solenoid valve,

2 position 4 way AE

Drive speed

select circuit

25 ft-

lbs / 34 Nm

Relief valve, 5

0 psi / 3,4 bar AF Brake release

20 ft-

lbs / 27 Nm

Solenoid valve,

3 position 5 way AG

Drive

forward/reverse

25 ft-

lbs / 34 Nm

Flow regulator and relief valve,

0.7

5 gpm / 2,8 L/min, 1500 psi / 103 bar

Steer circuit

26 ft-

lbs / 35 Nm

Solenoid valve,

2 position 4 way AI Platform up

25 ft-lbs / 34 Nm

Relief valve, 180

0 to 3700 psi / 124 to

5 bar

AJ Lift relief

20 ft-

lbs / 27 Nm

How to Install a Valve Cartridge

1 Dip the cartridge in clean oil to lube the O-rings.

2 Screw the cartridge in by hand until the top O-ring is met, then torque to specifications.

3 If required, install the valve coil(s) onto the valve stem. Install the coil nut onto the valve stem and

torque to specifications.
