Type "CXXX" Faults
Part No. 1309020GT GS
™
-30m • 32m • 30 • 32 • 46 • 55 199
Type "CXXX" Faults
DTC
Number
Message on
GCON LCD
Description
Possible Causes Failure Mode
C001:
C001:GCON ECM
FAULT TYPE 1
GCON ECM CRC check error.
• Incorrect software file.
• GCON ECM internal failure.
All functions
inhibited.
C004:
C004:GCON ECM
FAULT TYPE 4
GCON ECM master switch error.
• Short circuit in the master switch circuit.
• GCON ECM.
All functions
inhibited.
C005:
C005:GCOM ECM
FAULT TYPE 5
GCON ECM safety switch error.
• Short circuit in the safety switch circuit.
• GCON ECM.
All functions
inhibited.
C006:
C006:GCON ECM
FAULT TYPE 6
GCON input redundancy error.
• Input conditioning circuit failure.
• GCON ECM.
All functions
inhibited.
C007:
C007:GCON ECM
FAULT TYPE 7
GCON ECM inter-processor communication
error.
• Incorrectly programmed device.
• Error in loading software on device.
• GCON ECM.
All functions
inhibited.
C009:
C009:GCON ECM FAULT
FAULT TYPE 9
GCON ECM fault type 9. • Contact Genie support.
All functions
inhibited.
C010:
C010:SECONDARY
NOT PROGRAMMED
GCON secondary processor not
programmed.
• Incorrectly programmed device.
• Error in loading software on device.
• GCON ECM.
All functions
inhibited.
C021:
C021:PCON NOT
DETECTED
PCON not detected error.
• PCON disconnected.
• CAN communication failure.
• GCON or PCON ECM.
All functions
inhibited.
C023:
C023:MACHINE
MODEL FAULT
Discrepancy between model detected and
model programmed.
• Incorrect machine model programmed.
• GCON or PCON ECM.
All functions
inhibited.
C025:
C025:SYSTEMFAULT
PLAT OVLD:NOCAL
Platform overload system not calibrated.
• Platform overload system not calibrated.
• GCON or PCON ECM.
All functions
inhibited.
C028:
C028:SERVICE
OVERRIDE MODE ON
Machine is in service override mode.
• Machine programmed for use in service override
mode.
All functions inhibited
except for down
function and up
function.
Platform can be
elevated only once
with the maximum
elevate time of XX
seconds.
Elevate time XX
depends on machine
model.
