August 2021 Service and Repair Manual
Scissor Components
Part No. 1309020GT GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 145
19 Remove the fasteners securing the large
platform height bracket to the number 1 inner
arm pivot bracket.
20 Remove the large platform height sensor
bracket from the number 1 inner arm pivot
bracket.
Tip-over hazard. Failure to install
the fasteners securing the large
platform height sensor bracket
and number
1 inner arm pivot
bracket to the chassis, could
resu
lt in the machine tipping
over, causing death or serious
injury.
9-13
Lift Cylinders
How to Remove the Lift Cylinder
Bodily injury hazard. The
procedures in this section
require specific repair skills,
lifting equipment and a suita
ble
workshop. Attempting this
procedure without these skills
and tools could result in death or
serious injury and significant
component damage. Dealer
service is required.
Note: When removing a hose assembly or fitting,
the O-ring (if equipped) on the fitting and/or hose
end must be replaced. All connections must be
torqued to specification during installation. Refer to
Specifications, Hydraulic Hose and Fitting Torque
Specifications.
GS-1330m, GS-1432m, GS-1530, GS-1532,
GS-1930, GS-1932, GS-1932 XH, GS-
1932m, GS-1932m Lite, GS-1932m XH
1 Turn the key switch to ground controls and
pull out the red Emergency Stop button to the
on position at both ground and platform
controls.
2 Raise the platform 7 to 9 feet / 2,1 to 2,8 m.
To Next Page
