August 2021 Service and Repair Manual
Manifolds
Part No. 1309020GT GS
™
-30m • 32m • 30 • 32 • 46 • 55 57
5-9
Outrigger Manifold Components – GS-3232
The outrigger function manifold is mounted behind an inspection door, at the battery side of the machine.
Note: 'alpha-numeric' callouts refer to corresponding notes on the electrical schematic.
1
3 position 4 way BA
retract
25 ft-
2
0 psi / 241 bar BB Outrigger circuit
20 ft-
—
BA —
4-5 ft-lbs / 5-
How to Install a Valve Cartridge
1 Dip the cartridge in clean oil to lube the O-rings.
2 Screw the cartridge in by hand until the top O-ring is met, then torque to specifications.
3 If required, install the valve coil(s) onto the valve stem. Install the coil nut onto the valve stem and
torque to specifications.
